Images, SVG and draw.io

Format	How	Notes
HTML page	render, finalize	Standalone: no external requests. Diagram, Cost and Well-Architected tabs.
SVG	render --svg, finalize, or Export ▾ in the page	The page export is a dual-theme SVG (light, switching to dark when the viewer prefers it). Viewer state (focus, dimming, route, passport) is stripped.
PNG	render --png, finalize, or Export ▾ (also JPEG, WebP, copy to clipboard)	Needs Chrome/Chromium.
draw.io	export, render --drawio, finalize, or Export ▾ → Download draw.io (.drawio)	Uses draw.io's own Google Cloud icons. See below.
JSON receipt	finalize	Hashes and check results; see Quality gates.

draw.io

archify-gcp export spec.json -o diagram.drawio
archify-gcp render spec.json --drawio

The file opens in draw.io / diagrams.net (desktop, web, or the VS Code extension) and is fully editable.

What maps to what:

archify-gcp	draw.io
Google Cloud, organization, folder, project, region, zone, VPC, subnet, perimeter…	Styled container cells with the group's colour and dash and the official group icon in the corner
Nested groups	Real containers: move a group and its children follow
Edges	Attached to their icons, with the original waypoints and exit/entry points, open arrowheads, dashed style
Numbered callouts	Black numbered circles; the step description is the tooltip
Sequence diagram	Icons, dashed lifelines, message edges, alt/loop/par frames and notes

Notes on fidelity

• Layout is the archify-gcp layout. draw.io may re-route an edge a little when you drag things.
• An icon without a draw.io equivalent is embedded as the official SVG instead of failing; export tells you how many.
• Edge labels are real edge labels (they follow the edge); callout circles are separate shapes.
• The export is validated before it is written (unique ids, every reference resolves, every embedded icon is a valid SVG).

Presentation and documents

• Use --theme dark for slides and keep light for documents. Training and certification diagrams should use light.
• For a portrait page (Word, blogs) prefer column layouts at the root.
• PNG size follows the diagram; scale it in your document rather than re-flowing the spec.

Icon licensing

Icons are © Google LLC. Use them to depict Google Cloud architecture, do not alter them, and do not imply Google endorsement. Rendered pages embed the icons they use; check the current Google terms for the icons before publishing diagrams widely.
